STRADDLE TRACTOR OPTIMUM 245

The connected, multi-function vineyard straddle dedicated to narrow vineyards

Designed to meet the needs of winegrowers working in narrow vineyards, the OPTIMUM 245 vineyard tractor combines manoeuvrability, power and versatility. Capable of working on two or three rows simultaneously, it can be adapted to any vineyard tasks, from tillage to spraying, and guarantees optimal yields all year round.

Thanks to its PELLENC CONNECT connectivity, it allows precise monitoring of each plot and each tool, both in the field and remotely, to optimise every pass.

Find a dealer Request a quote



• Request a demo

Exceptional manoeuvrability in narrow vineyards

Day-to-day cab comfort and safety

Panoramic vision and enhanced visibility

Intuitive straddle steering and PELLENC CONNECT connectivity

Power, traction and stability of the high-clearance tractor

Exceptional manoeuvrability in narrow vineyards

• Robust, well-balanced design: three available beam heights (1,500, 1,600 and 1,750 mm) and low centre of gravity for perfect stability, even on steep terrain
• Optimised steering: short wheelbase, 90° steering angle and reduced turning radius for fast U-turns on headlands
• Hydraulic variable track: inter-row width adjustable from 0.9 to 1.5 m directly from the cab using the EASY TOUCH joystick
• Multi-row working: ability to working on two or three rows simultaneously to increase productivity in all vineyard tasks

Day-to-day cab comfort and safety

• Category 4 pressurised cab (EN 15695) with optimal filtration, reduced noise level
• Heated, ventilated and ergonomically designed GRAMMER seat to reduce fatigue
• Plenty of storage space, Bluetooth radio, USB ports, 12V socket, refrigerated storage and LED interior lighting

Panoramic vision and enhanced visibility

• Central cab with curved windows and narrow pillars for a wider field of vision
• 12 LED work lights and HD colour manoeuvring cameras with night vision* for day/night visibility
• Electrically heated rear-view mirrors and colour manoeuvring cameras

*Optional

Intuitive straddle steering and PELLENC CONNECT connectivity

• EASY DRIVE multifunction joystick and EASY TOUCH 10" touchscreen for quick and easy adjustments
• Customisable controls depending on the attachment and integrated maintenance diagnostics
• Real-time monitoring and data feedback via PELLENC CONNECT

Power, traction and stability of the high-clearance tractor

• 136 HP Perkins Stage V engine, with high torque and optimised fuel consumption
• Poclain 4-wheel drive and TWINLOCK traction control system for optimum traction from your high-clearance tractor
• Low centre of gravity for excellent stability on slopes

245 VITICULTURAL STRADDLE TRACTOR

STRADDLE TRACTOR 245

A high-clearance tractor for all vineyard work Fast, versatile attachment Precise spraying with the E-SPRAYER SD and SM Simplified control with the MULTIVITI 12 chassis High-performance, precise topping and trimming Pruning machines, different technologies for customised pruning Horizontal axis mower, perfect for narrow vineyards Quick and easy maintenance

The OPTIMUM 245 vineyard straddle tractor is designed to perform all types of vineyard work: mowing, topping, pruning, spraying and tilling. Its compatibility with all tools guarantees maximum versatility and an optimised return on investment.

The OPTIMUM 245 vineyard straddle tractor is equipped with push, pull and rear tool carriers, offering exceptional versatility to adapt to all types of tools. This flexibility means you can carry out all your vineyard work - from soil maintenance to pruning and spraying - all year round.

E-SPRAYER electric sprayers reduce drift, optimise dosage and offer rapid application. Ideal for narrow vineyards, they improve treatment quality and reduce losses.

The MULTIVITI 12 chassis ensures safe attachment and centralised control of implements from the cab. Compact and ergonomic, it makes manoeuvring easier and increases productivity in all conditions. It has been designed to easily accommodate the pruner, making it easy to carry out pruning and trimming, as well as pre-pruners for narrow vineyards.

Designed to adapt to all trellis heights, the F34_C DRIVE pruner guarantees a clean, regular cut. Its optimised cutterbars enable rapid topping even in dense vegetation, while preserving the quality of the vines.

Pre-pruners for narrow vineyards are designed to be fast, precise and adaptable to your needs and your plots. They offer different cutting systems, with two optional detection systems available:

• DISCO cutting system:
  • Ideal for difficult terrain, including slopes.
  • Lightweight and compact for easy passage through all types of field.
  • Robust disc system, clean cut and low maintenance.
  • High-quality steel discs for exceptional durability without frequent sharpening.



• MARGUERITES cutting system:
  • Excellent quality of cut and crumbling, even in dense vegetation.
  • Blade/counter-blade system limits splashing and protects the wires.
  • Ideal for farms looking for a neat finish.
  • Double-sharpened Pradines blades for increased durability and reduced maintenance.



• Optical detection*:
  • Automatic opening by optical detection as posts pass by.
  • Precise, thorough cleaning around posts that saves time when pruning.
  • Adjustable settings for different types of post.



• 2-row magnetic detection*:
  • Specially adapted to vineyards trained with metal posts.
  • Ultra-sensitive magnetic detection of stakes for automatic opening/closing of cutting heads, even at 9 km/h.
  • Clean cut, with crumbled wood removed by gravity and maximum time savings.

*Depending on model, options and network availability

The PELLENC horizontal-axis mower is designed for narrow vineyards with a row spacing of 1 m or more. Its high-speed rotor and precise ground tracking ensure a uniform cut on all types of soil, even stony ones.

All control and maintenance points (lubrication, filters, oils) are accessible without tools. Built-in self-diagnostics via the EASY TOUCH screen and maintenance reminders keep downtime to a minimum.

Technical features

245 STRADDLE TRACTOR
Height under beam	1 500 ; 1 600 ; 1 750 mm
Number of rows	Double to triple row
Homologation	T4-1
Width of vines	0.9 to 1.5 m
Overall height	3 505 mm
Overall width	2 530 mm
Overall length	3 665 mm
Pneumatic seat	Yes
Cab access ladder	Yes
Electric mirrors	Yes
Trip computer and multifunction joystick	Yes
Protective hoop	NF U02-052 standard
Work light	14 in total
Parking brake	Automatic
Minimum turning radius	3.4 m
Crossing capacity	40 %
Wheelbase	2.56 m
Road speed	30 km/h
Displacement	3.6 L
Engine technology	Stage 5
Engine power	136 Cv
Speed limiter	Yes
Fuel tank	2 x 65 L
4-wheel drive POCLAIN	Yes
TWINLOCK anti-skid system	Yes
Front tyres	280/80 R18 or 340/80 R18
Rear tyre	280/85 R24 or 340/85 or 380/70 R24
Pumps and maximum flow rates	LS flow: 130 lpm at 280b/60 lpm at 180b Option: LS flow rate/60 lpm at 180b Gear pump flow: 35 lmp at 200b
Distributors	9 hydraulic spool valves as standard, up to 12 as an option
Compatible tools	E-SPRAYER SD and SM sprayers; MULTIVITI 12 chassis; F34_C DRIVE pruner; 2-row magnetic pruner; DISCO and MARGUERITES pruners; Horizontal axis mower
